| Engine Type | 999cc liquid cooled, 4-stroke, DOHC, 4-valve |
| Bore x Stroke | 93.0mm×73.5mm |
| Compression Ratio | 11.2:1 |
| Fuel Delivery | Yamaha Fuel Injection (YFI); dual 48mm throttle bodies |
| Transmission | Ultramatic V-belt with all-wheel engine braking; L, H, N, R |
| Final Drive | On-Command 4-way locking differential; Turf Mode, 2WD, 4WD, full diff-lock 4WD |
| Fuel Capacity | 9.2 gal |
| Suspension / Front | Independent double wishbone with anti-sway bar, FOX® iQS piggyback shocks; 14.2-in travel |
| Suspension / Rear | Independent double wishbone with anti-sway bar, FOX® iQS piggyback shocks; 16.9-in travel |
| Brakes | Front & Rear: Dual hydraulic disc |
| Tires - Front | 30 x 10.00R-14 Maxxis® Carnivore |
| Tires - Rear | 30 x 10.00R-14 Maxxis® Carnivore |
| Dimensions | LxBxH: 150.8 in x 66.7 in x 82.7 in |
| Wheelbase | 118.1 in |
| Fuel Capacity | 9.2 gal |
| Wet Weight | 2,370 lbs |
| Stock Status | In Stock |
| Engine Type | 847cc parallel-twin, liquid-cooled, DOHC; 4 valves |
| Bore x Stroke | 82.0mm x 80.2mm |
| Compression Ratio | 10.5:1 |
| Fuel Delivery | Yamaha Fuel Injection (YFI); dual 36mm throttle bodies |
| Transmission | Ultramatic V-belt with all-wheel engine braking; L, H, N, R |
| Final Drive | On-Command 3-way locking differential; 2WD, 4WD, full diff-lock 4WD |
| Fuel Capacity | 9.2 gal |
| Suspension / Front | Independent double wishbone with anti-sway bar, fully adjustable KYB® piggyback shocks; 8.7-in travel |
| Suspension / Rear | Independent double wishbone with anti-sway bar, self-adjusting shock absorbers; 9.3-in travel |
| Brakes | Front & Rear: Dual hydraulic disc |
| Tires - Front | AT27 x 9-12 GBC® Dirt Commander |
| Tires - Rear | AT27 x 11-12 GBC® Dirt Commander |
| Dimensions | LxBxH: 122.0 in x 62.2 in x 77.7 in |
| Wheelbase | 83.7 in |
| Fuel Capacity | 9.2 gal |
| Wet Weight | 1,893 lbs |
| Stock Status | Pre-Order |
| Engine Type | 999cc liquid cooled, 4-stroke, DOHC, 4-valve |
| Bore x Stroke | 93.0mm×73.5mm |
| Compression Ratio | 11.2:1 |
| Fuel Delivery | Yamaha Fuel Injection (YFI); dual 48mm throttle bodies |
| Transmission | Ultramatic V-belt with all-wheel engine braking; L, H, N, R |
| Final Drive | On-Command 3-way locking differential; 2WD, 4WD, full diff-lock 4WD |
| Fuel Capacity | 9.2 gal |
| Suspension / Front | Independent double wishbone with anti-sway bar; SACHS® ZF piggyback shocks with compression and preload adjustability; 13.3-in travel |
| Suspension / Rear | Independent double wishbone with anti-sway bar; SACHS® ZF piggyback shocks with compression and preload adjustability; 15.5-in travel |
| Brakes | Front & Rear: Dual hydraulic disc |
| Tires - Front | 28 x 10.00R-14 Maxxis® Bighorn |
| Tires - Rear | 28 x 10.00R-14 Maxxis® Bighorn |
| Dimensions | LxBxH: 115.0 in x 63.6 in x 77.2 in |
| Wheelbase | 83.7 in |
| Fuel Capacity | 9.2 gal |
| Wet Weight | 1,820 lbs |
| Stock Status | Pre-Order |
| Engine Type | 999cc liquid cooled, 4-stroke, DOHC, 4-valve |
| Bore x Stroke | 93.0mm×73.5mm |
| Compression Ratio | 11.2:1 |
| Fuel Delivery | Yamaha Fuel Injection (YFI); dual 48mm throttle bodies |
| Transmission | Ultramatic V-belt with all-wheel engine braking; L, H, N, R |
| Final Drive | On-Command 4-way locking differential; Turf Mode, 2WD, 4WD, full diff-lock 4WD |
| Fuel Capacity | 9.2 gal |
| Suspension / Front | Independent double wishbone with anti-sway bar, FOX® 2.0 piggyback shocks with pre-load, high/low speed compression adjustability; 14.2-in travel |
| Suspension / Rear | Independent double wishbone, FOX® 2.0 piggyback shocks with pre-load, high/low speed compression adjustability; 16.9-in travel |
| Brakes | Front & Rear: Dual hydraulic disc |
| Tires - Front | 30 x 10.00R-14 GBC® Terra Master |
| Tires - Rear | 30 x 10.00R-14 GBC® Terra Master |
| Dimensions | LxBxH: 119.3 in x 66.1 in x 77.8 in |
| Wheelbase | 86.7 in |
| Fuel Capacity | 9.2 gal |
| Wet Weight | 1,962 lbs |
| Stock Status | In Stock |
| Engine Type | 847cc parallel-twin, liquid-cooled, 4-stroke, DOHC, 4-valve |
| Bore x Stroke | 82.0mm x 80.2mm |
| Compression Ratio | 10.5:1 |
| Fuel Delivery | Yamaha Fuel Injection (YFI); dual 36mm throttle bodies |
| Transmission | Ultramatic V-belt with all-wheel engine braking; L, H, N, R |
| Final Drive | On-Command 3-way locking differential; 2WD, 4WD, full diff-lock 4WD |
| Fuel Capacity | 9.2 gal |
| Suspension / Front | Independent double wishbone with anti-sway bar, fully adjustable KYB® piggyback shocks; 8.7-in travel |
| Suspension / Rear | Independent double wishbone with anti-sway bar, fully adjustable KYB® piggyback shocks; 9.3-in travel |
| Brakes | Front & Rear: Dual hydraulic disc |
| Tires - Front | AT27 x 9-12 GBC® Dirt Commander |
| Tires - Rear | AT27 x 11-12 GBC® Dirt Commander |
| Dimensions | LxBxH: 115.0 in x 62.2 in x 75.3 in |
| Wheelbase | 83.7 in |
| Fuel Capacity | 9.2 gal |
| Wet Weight | 1,704 lbs |
| Stock Status | Pre-Order |
| Engine Type | 686cc liquid-cooled SOHC 4-stroke; 4 valves |
| Bore x Stroke | 102.0mm x 84.0mm |
| Compression Ratio | 10.0:1 |
| Fuel Delivery | Yamaha Fuel Injection (YFI) |
| Transmission | Ultramatic V-belt with all-wheel engine braking; L, H, N, R |
| Final Drive | On-Command; 3-way locking differential; 2WD, 4WD, locked 4WD; shaft drive |
| Fuel Capacity | 9.7 gal |
| Suspension / Front | Independent double wishbone; 8.1-in travel |
| Suspension / Rear | Independent double wishbone with anti-sway bar; 8.1-in travel |
| Brakes | Front & Rear: Dual hydraulic disc |
| Tires - Front | AT25 x 8-12 |
| Tires - Rear | AT25 x 10-12 |
| Dimensions | LxBxH: 159.5 in x 64.0 in x 76.6 in |
| Wheelbase | 115.6 in |
| Fuel Capacity | 9.7 gal |
| Wet Weight | 1,761 lbs |
| Stock Status | In Stock |
| Engine Type | 686cc liquid-cooled SOHC 4-stroke; 4 valves |
| Bore x Stroke | 102.0mm x 84.0mm |
| Compression Ratio | 10.0:1 |
| Fuel Delivery | Yamaha Fuel Injection (YFI) |
| Transmission | Ultramatic V-belt with all-wheel engine braking; L, H, N, R |
| Final Drive | On-Command; 3-way locking differential; 2WD, 4WD, locked 4WD; shaft drive |
| Fuel Capacity | 9.7 gal |
| Suspension / Front | Independent double wishbone; 8.1-in travel |
| Suspension / Rear | Independent double wishbone; 8.1-in travel |
| Brakes | Front & Rear: Dual hydraulic disc |
| Tires - Front | AT25 x 8-12 |
| Tires - Rear | AT25 x 10-12 |
| Dimensions | LxBxH: 122.1 in x 61.8 in x 75.8 in |
| Wheelbase | 84.1 in |
| Fuel Capacity | 9.7 gal |
| Wet Weight | 1,475 lbs |
| Stock Status | In Stock |
